pıoneer tsw2541dvc
Don't even think about this sub unless you have a serious, over-the-top love of tight, deep bass. The 10" TS-W2541DVC will be in your face with 700 Watts of clean power, and features Pioneer's Voice Coil Cooling System (VCCS) to keep the temp down and the sound quality high, despite hours of nearly criminal power levels. And, a dual voice coil design allows you some extra system options.
bullet 10" VCCS PRO Component Subwoofer
bullet Foamed IMPP (Injection Molded Polypropylene) Rigilite™ Composite Cone Woofer
bullet Aluminum Insert for Increased Cone Rigidity
bullet Dual-Layer Urethane Surround
bullet Direct Bobbin Mounted VCCS (Voice Coil Cooling System)
bullet Conex Damper with Damper Ring
bullet Lead Wires Integrated into Damper for High Reliability and Improved Power Transfer
bullet Projected Pole Yoke with Vented Pole
bullet High-Energy Ferrite Magnet with Bumped Back Plate
bullet Low-Q Design for use in Small Sealed Box (0.6 cubic foot recommended)
bullet Dual Voice Coil (2x4W ) Design for Increased System Flexibility
bullet 700 Watts Max Music Power
bullet 350 Watts Nominal Power Handling
bullet Frequency Response: 18-2,500Hz
bullet Sensitivity (Efficiency): 86dB (1W/1m)
bullet 2Ohm or 8Ohm Rated
PIONEER TS W301r
» 12″ 4-ohm subwoofer
» composite IMPP cone with wide roll urethane surround
» power range: 50-150 RMS watts (800 watts peak power)
» frequency response: 20-4000 Hz
» sensitivity: 91 dB
» mounting depth: 5-3/4″
» sealed box volume: 1.00-2.00 cu. ft.
» ported box volume: 1.25-2.05 cu. ft.
pıoneer tsw 300R
Great design and materials = great sub. The TS-W300R handles 600 watts max., 150 watts nominal power, and features Pioneer�s extremely strong and lightweight IMPP Composite Cone Woofer, for improved sensitivity and reduced distortion. The Conex Damper with Damper Ring delivers higher power handling and deeper bass, and the 4-Layer Long Voice Coil adds extra power and control. The Dual-Layer Urethane Surround provides excellent linearity on the long excursion, and the Projected Pole Yoke with Vented Pole delivers tight, powerful bass, with lower distortion. Accessory grill available (UD-G305).
pıoneer TS-W3004SPL
Stand back. The Premier TS-W3004SPL subwoofer is designed to produce enormously powerful music. Just take a look at its super-heavy-duty construction, all designed to handle up to 3,000 watts max. The titanium voice coil bobbin. The ceramic-coated voice coil wire. Double-stacked magnets for higher power, and a step-up radial surround for superior control and long excursions. We used an aluminum heat sink and even constructed a cast-aluminum basket for this sub. Add in our patented IMPP cone and you've got a monster sub that can handle whatever you want to throw at it — including Pioneer's new breed of SPL amplifiers like the PRS-D3000SPL.
Titanium Voice Coil Bobbin
With a subwoofer capable of handling this much power, ALL of its parts have to be up to the task. No weak links, and this even includes the voice coil bobbin. To make sure the TS-W3004SPL's voice coil bobbin was virtually indestructible, we created them from titanium. No weak link here.
Ceramic-Coated Voice Coil Wire
The TS-W3004SPL's voice coil wire is coated with ceramic, which allows it to handle extreme heat. This doubles the input power handling capability and significantly improves reliability. This technology is proven, with consecutive dB Drag Racing DeathMatch competition wins at the 2003 and 2004 dB Drag Racing World Finals!
Double-Stack Magnet with Double-Stack Top Plate
To produce the tremendous magnetic energy we envisioned for this sub, we employed double-stacked magnets, weighing a hefty 110oz, and a double-stacked top plate above them. This design ensures positive, powerful control of the voice coil during those long excursions — and it's one reason you can ring up those high SPL numbers.
Wide-Roll 3-Layer Fiber Radial Surround
A sub's surround plays a key role in a speaker's performance. In order for bass response to be clear and tight, the surround has to respond evenly around its entire circumference without flexing or puckering, even at high volume levels. That's why Pioneer created a surround consisting of two layers of urethane with a layer of interwoven fiber between them. It's strong, stable, and it reduces distortion. In addition, the wider-than-normal design provides a long, linear excursion for excellent control and heavy-duty durability.
IMPP Cone with Carbon Fiber/Glass Fiber Reinforcement
Pioneer invented the process of injection-molding polypropylene to form a speaker cone. We call them IMPP cones, and they're exceptionally strong and lightweight. Now, we've reinforced IMPP with carbon and glass fiber, providing speaker cones with extraordinary strength and rigidity — and light weight. This is ideal for powerful, accurate music. And it gives the cones the durability needed for withstanding heat, humidity, and dust.
Aluminum Heat Sink
In creating huge magnetic force, magnets can get very hot. And heat can create distortion. So, we included an aluminum heat sink that cools the voice coil structure.
Cast Aluminum Basket
Designed from scratch by Pioneer, this one-piece aluminum basket assembly holds the motor assembly, cone, and magnet structure securely in place. The benefits of this design: reduced internal stress, superior damping, and increased magnetic efficiency.
Dual Voice Coil
TS-W3004SPL uses two voice coils, each at 4 ohms. This design offers you the flexibility of turning it into either a 2-ohm sub (voice coils connected in parallel), an 8-ohm sub (connected in a series), or powering the voice coils separately (dual 4 ohm loads). More options, more power: that's what DVC is all about.
Pioneer TS-W302R
Pioneer TS-W302R Component Subwoofer 12-Inch with 800 Watts Max. Power, 150 Watts Nominal Power, 4-Ohm Single Voice Coil Design, Recommended Enclosure Use: 1.0 ~ 2.0 Cubic Feet, Frequency Response 20 ~ 4,000Hz, Sensitivity 97 dB, Ohm Rating 4, IMPP Composite Cone Woofer Material (TSW302R TS W302R TSW-302R TS-W302)
PIONEER TS W12PRS
PIONEER Premier TS W12PRS - Product features frequency response: 15 - 2.000 hz sensitivity (1w/1m): 92 db qts: 0,39 recommended sealed enclosure (litres): 28 lowest resonance frequency
pıoneer tsw 307 d2
Features:
12"
# 1200w
# 400w rms
# spl: 89 db
# 18 hz–500 hz
# dual 2_ voice coil
# trickle-down technology from spl woofers provide maximum performance
# dual voice coil design maximizes flexibility
# integrated single-sided terminals with 4_ bridging adapter
# aramid fiber impp composite cone
# 3-layer fiber woven radial surround
# aluminum voice coil bobbin
# integrated single-sided terminals
weight: 16.3 (lbs)
Pioneer TS-W257D2
Pioneer TS-W257D2 Dual 2-Ohm Subwoofer, 10" Dual 2 ohms Component Subwoofer, 1000 Watts RMS Power Handling, 350 Watts Peak Power Handling, Dual 2 ohms Impedance, Aramid fiber IMPP composite cone, Dual Mass Magnet with Magnet Cover, Spring-Compression Binding Posts (TSW257D2 TS W257D2)
pıoneer TS-W257D4
The TS-W257D4 offers you a variety of set-up possibilities (8Ω or 2Ω), provided that there is correct power matching between the subwoofer and your amplifier.
So, whether you are building your system from an existing stereo or mono amp, or whether you want a basic set-up with expandability potential, the TS-W257D4 will cover common impedance loads.
IMPP ConeThe IMPP™ (Injection Moulded Polypropylene) cone is constructed from a composite blend of interlaced Aramid fibres, which make it extremely rigid; yet lightweight, for low distortion and powerful bass at high sound press levels.
The speaker terminals have been placed on one side of the subwoofer, rather than on both sides as with conventional subs; this gives you greater installation flexibility.
Pioneer TS-W252R
The Pioneer TS-W252R is a 10" Champion Series subwoofer capable of handling a maximum of 600 Watts power and 120 Watts nominally(RMS). This is more of a budget subwoofer which features include a Strontium magnet, 4-Layer long voice coil, Wide-Roll Dual-Layer Urethane surround and Aramid fiber damper ring.
pıoneer tsw 383 dvc
Features
* Diamondplate Foamed IMPP (Injection Molded Polypropylene) Rigilite™ Composite Cone Woofer (Titanium Grey)
* One-Piece Cone Construction for Reduced Distortion
* Dual-Layer Urethane Surround
* Direct-to-Cone Voice Coil Mounting Ring
* Conex Damper with Damper Ring
* Lead Wires Integrated into Damper for High Reliability and Improved Power Transfer
* Oversized Glass-Imide Voice Coil Bobbin
* Projected Pole Yoke with Vented Pole
* High-Energy Strontium Magnet
* Low-Q Design for use in Small Sealed Box (1.2 cubic foot recommended)
* 500 Watts Max Music Power
* Frequency Response: 15-1,500Hz
* Sensitivity (Efficiency): 94dB (1W/1m)
